Product Information:

Hydrogen purity: ≥99.999%.

2.Output flow rate (ml/min): 0-1020.

3.Output pressure (MPa):0.02-0.4.

4. Pressure stability: < 0.001MPa

Applications:

GC (gas phase) gas and carrier gas ELCD (conductivity detector) reaction gas ED (atomic emission detector) reaction gas.

Product Parameters:

1. Hydrogen purity: ≥99.999%.

2.★Output flow rate (ml/min): 0-1020.

3.★Output pressure (MPa):0.02-0.4.

4. Pressure stability: < 0.001MPa

5. Input power (w) <500.

6. Dimensions (L*W*H): 485mm×368mm×352mm.

7. Power supply voltage (V): AC 220 50-60Hz.

8. Water quality requirements: deionized water or secondary distilled water (resistivity ≥ 1MΩ).

9. It has a built-in 2L large-capacity water storage tank

10. Use molecular sieve drying cylinder to dry hydrogen for a long time and efficiently

11. Machine weight (Kg): <20.
